HOME > Meters > Ampere > Specification D-800 D-60 D-200   Shape of case Type   Rated Curr. Operating Princ. Accur.(%) Freq. Burden(VA) Rectangular(60×60㎜) D-60 AC DC 5A 50,60mV ±2.5 ±2.5 60Hz 1.0 50mV Drop Rectangular(60×80㎜) D-68 AC DC 5A 50,60mV ±2.5 ±2.5 60Hz 1.0 50mV Drop Rectangular(80×80㎜) D-80 AC DC 5A 50,60mV ±2.5 ±2.5 60Hz 1.0 50mV Drop Rectangular(100×83㎜) D-100 AC DC 5A 50,60mV ±1.5 ±1.5 60Hz 1.0 50mV Drop Rectangular(80×80㎜) D-800 AC DC 5A 50,60mV ±1.5 ±1.5 60Hz 1.0 50mV Drop Rectangular(110×110㎜) D-110 AC DC 5A 50,60mV ±1.5 ±1.5 60Hz 1.0 50mV Drop Rectangular(70φ) D-70 AC DC 5A 50,60mV ±2.5 ±2.5 60Hz 1.0 50mV Drop Rectangular(72×72㎜) D-200 AC DC 5A 50,60mV ±1.5 ±1.5 60Hz 1.0 50mV Drop Rectangular(98×98㎜) D-300 AC DC 5A 50,60mV ±1.5 ±1.5 60Hz 1.0 50mV Drop Type Directly rating CT rating (VA) minimum maximum minimum maximum Rectifier 100mA 30A */ 1A */ 5A 0.1 Moving iron 30mA 30A */ 1A */ 5A 1.5 Type Directly rating Shunt rating minimum maximum minimum maximum Moving Coil Type 50㎂ 30A */ 50mV */ 200mV Company  +  Transducers  +  Meters  +  Transformer  +  Support  +  Board
