| Shape
of case |
Type |
|
Rated
Curr. |
Operating
Princ. |
Accur.(%) |
Freq. |
Burden(VA) |
| Rectangular(60×60㎜) |
D-60 |
AC
DC |
150,300V
1, 600V |
|
±2.5
±2.5 |
60Hz |
5.0,0.5
1KΩ/v |
| Rectangular(60×80㎜) |
D-68 |
AC
DC |
150,300V
1, 600V |
|
±2.5
±2.5 |
60Hz |
5.0,0.5
1KΩ/v |
| Rectangular(80×80㎜) |
D-80 |
AC
DC |
150,300V
1, 600V |
|
±1.5
±1.5 |
60Hz |
5.0,0.5
1KΩ/v |
| Rectangular(100×83㎜) |
D-100 |
AC
DC |
150,300V
1, 600V |
|
±1.5
±1.5 |
60Hz |
5.0,0.5
1KΩ/v |
| Rectangular(80×80㎜)광각 |
D-800 |
AC
DC |
150,300V
1, 600V |
|
±1.5
±1.5 |
60Hz |
0.5
1KΩ/v |
| Rectangular(110×110㎜)광각 |
D-110 |
AC
DC |
150,300V
1, 600V |
|
±1.5
±1.5 |
60Hz |
0.5
1KΩ/v |
| Rectangular(70φ) |
D-70 |
AC
DC |
150,300V
1, 600V |
|
±2.5
±2.5 |
60Hz |
0.5
1KΩ/v |
| Rectangular(72×72㎜) |
D-200 |
AC
DC |
150,300V
1, 600V |
|
±1.5
±1.5 |
60Hz |
0.5
1KΩ/v |
| Rectangular(98×98㎜) |
D-300 |
AC
DC |
150,300V
1, 600V |
|
±1.5
±1.5 |
60Hz |
0.5
1KΩ/v |
|
 |
|
|
|
| 형식 |
직결사용 |
CT사용 |
(VA) |
| 최저측정치 |
최대측정치 |
최저측정치 |
최대측정치 |
정류형  |
18V |
600V |
- |
*/ 110V |
0.5 |
철편형  |
30V |
300V |
- |
*/ 220V |
5.0 |
|
|
|
 |
|
|
|
|
|
| 형식 |
직결사용 |
Multifler사용 |
| 최저측정치 |
최대측정치 |
최저측정치 |
최대측정치 |
가동 Coil 형식  |
50mV |
750V |
- |
*/ 10V |
|
|
